The 300Mbps Wireless N Home Router delivers the highest level of security with 12x the speed and 4x the range of wireless g products. Quickly install the router and use it with TRENDnet wireless n adapters to receive the full benefits of wireless n speed and coverage.
The latest in wireless encryption and a secure firewall provide the ultimate in wired and wireless security. Advanced Multiple Input Multiple Output (MIMO) antenna technology delivers expansive coverage and eliminates dead spots. A quick and intuitive installation process, one touch wireless connection using Wi-Fi Protected Setup and advanced management capabilities make this product well suited for your most demanding home networking needs.
 |
- Wi-Fi compliant with IEEE 802.11n and IEEE 802.11b/g standards
- 4 x 10/100Mbps Auto-MDIX LAN port and 1 x 10/100Mbps WAN port (Internet)
- Supports Cable/DSL modems with Dynamic IP, Static IP, PPPoE, PPTP, L2TP & BigPond connection types
- High-speed data rates up to 300Mbps using an IEEE 802.11n connection
- 2 fixed external antennas support high speed performance and great coverage with MIMO technology
- Network Address Translation (NAT) firewall
- Wi-Fi Protected Setup (WPS) button for simple network connectivity
- Universal Plug and Play (UPnP) and Application Level Gateway support for Internet applications such as email, FTP, gaming, remote desktop, Net Meeting, telnet and more
- Provides additional security with Internet Access Control (MAC Address, Domain, and IP Filtering)
- Easy remote management via Web browser
- Wireless security support for WEP, WPA &WPA2
- Indoor coverage up to 100 meters (330ft.)*
- Outdoor coverage up to 300 meters (980ft.)*
- Works with Windows, Linux and Mac operating systems
- 3-year limited warranty
*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending on interference, network traffic, building materials and other conditions.
** Internet Explorer 6.0 and above is recommended
| Hardware | |
| Standards |
|
| WAN | 1 x 10/100Mbps Auto-MDIX port (Internet) |
| LAN | 4 x 10/100Mbps Auto-MDIX ports |
| WPS Button | Enables Wi-Fi Protected Setup (WPS) function |
| Connection Type | Dynamic IP, Static (Fixed) IP, PPPoE, PPTP, L2TP |
| UPnP | UPnP IGD 1.0 compliant |
| DMZ | DMZ host & Virtual Servers |
| DNS | Static or WAN assigned DNS servers; 3 verified services for DDNS |
| SNMP | Up to 3 external trap receivers |
| Internet Access Control | MAC Address Filter, Domain/URL Filter, Protocol/IP Filter |
| Logging | 5 types of event logging; email report |
| LED Indicator | Power, LAN1~LAN4, WAN, WLAN, Status |
| Power Switch | On/Off power switch |
| Power Adapter |
|
| Power Consumption | 3.0 watts (max) |
| Dimension (L x W x H) | 149 x 109 x 29mm (5.9 x 4.3 x 1.1in) |
| Weight | 238g (8.4oz) |
| Temperature |
|
| Humidity | Max. 90% (non-condensing) |
| Certifications | CE, FCC |
| Wireless | |
| Frequency | 2.412~2.484GHz band |
| Antenna | 2 x 2dBi fixed dipole antennas |
| Media Access Protocol | CSMA/CA with ACK |
| Data Rate |
|
| Security |
|
| Output Power |
|
| Receiving Sensitivity |
|
| Channels | 1~ 11 (FCC), 1~13 (ETSI) |
